Features
PRODUCT FEATURES
Phase-Corrected BAK4 Roof Prisms
Fully Multicoated Optics
Angle of View: 52°
Nitrogen-Filled, Water and Fogproof
Open Bridge Configuration
Reinforced Polycarbonate Housing
Centre Focusing
Tripod Mountable
Twist-Up EyecupsOVERVIEW
Designed for the nature-enthusiast who wants to pack light without sacrificing image quality, the Pentax 8x36 AD WP Compact Binocular delivers bright clear images while weighing in at just 22.5 ounces. The BAK4 roof prisms are phase-corrected to improve image contrast and enhance colour rendition. All of the optics are anti-reflection fully multicoated to maximize light transmission to produce the brightest views possible.
In order to cut weight, the housing is made of corrosion and impact-resistant fibreglass reinforced polycarbonate polymer. The material is also temperature-resistant allowing for its use in extreme climates while reducing expansion and contraction wide temperature swings can cause which can make the optical components move out of collimation over time. Its optical tubes are nitrogen-filled and O-ring sealed so they can are submersible to 3.3', as well as fogproof in all weather conditions.
Optical Performance
8x magnification
36mm objective lenses
BAK4 roof prisms
Phase corrected prism coatings enhance contrast and improve colour rendition
Anti-reflection fully multicoated optics
341.5' field of view at 1000 yards
52° angle of view
Use and Handling
Open bridge configuration reduces weight and provides larger gripping area
Knurled centre focusing wheel
Twist-up eyecups for use with or without eye wear
16.0mm eye relief, 4.5mm exit pupil
Tripod mountable with optional adapter
Construction Details
Lightweight fibreglass reinforced polycarbonate housing
Housing is corrosion, temperature and impact-resistant
Nitrogen-filled for fogproof performance, submersible to 3.3' (1m)
Rubberised armouring protects against impacts and provides slip-resistant grip
Inner focusing mechanism provides smooth focus while preserving waterproof seals
SPECIFICATIONS
Prism Type Roof
Magnification 8x
Objective Lens Diameter 36 mm
Angle of View 6.5° (actual)
Field-of-View 341.5' @ 1000 yd / 113.38 m @ 1000 m
Minimum Focus Distance9.84' / 3 m
Exit Pupil Diameter 4.5 mm
Eye Relief 16 mm
Focus Type Centre
Tripod Mount Yes (Adapter Optional)
Dimensions 6.1 x 5.1 x 2.1" / 15.49 x 12.95 x 5.33 cm
Weight 22.5 oz / 638 g
Specifications
Included in the box
Pentax 8x36 AD WP Binocular
Neck Strap
Carrying Case with Strap
2 x Objective Lens Caps
2 x Eyepiece Caps
Warranty
From the original date of purchase, RICOH IMAGING CANADA INC. provides a limited Canadian lifetime warranty for most* PENTAX Binoculars purchased within Canada from a Ricoh Imaging authorized dealer. This warranty covers the original owner and is not transferable. Routine external cleaning, normal cosmetic and mechanical wear and excessive wear due to professional use are not covered under the terms of this limited Canadian lifetime binocular warranty.
*Exceptions
The PENTAX Jupiter binocular series include a limited one-year manufacturer’s warranty.
PENTAX Spotting Scopes, Eyepieces, Zoom Binoculars and Monoculars include a limited five-year manufacturer’s warranty.
